Front Panel
Jack input
Clean channel volume control
3 way channel switch.
(Up = Clean, Down = Overdrive, Mid = Foot switch / Combined channels)
Overdrive gain control
Overdrive volume control
Sound controls - Bass, Mid, Treble, Reverb
Standby switch
Power switch
Rear Panel
Mains fuse
Speaker plug
15/30 Watt power switch
DI Output level control
DI Balanced line XLR output socket
Dimensions
Depth: 10 ins - 254 mm
Height: 17 ins - 432 mm
Width: 167⁄8 ins - 428 mm
Weight
35lbs / 16.0 kg - Excluding foot switch and cover
36lbs / 16.5 kg - Including foot switch and cover
Mains Lead: Detachable standard IEC (kettle) connector
Mains input selectable for 240 or 120 volts
Footswitch (detachable): 4 metre lead
Available in 6 colours of vinyl covering. Click image on the right to view colour swatches (swatches are available on request). Leather stitched handles and full set of protective metal corners.
Fitted padded cover, footswitch and cable included in price
3 year Warranty on parts and labour (excluding valves)
|
